by Ryan Morrison
June 04, 2021

from DailyMail Website







A cut-away of Earth's interior

shows the solid iron inner core (red)

slowly growing by freezing of the liquid iron outer core (orange).

Seismic waves travel through the Earth's inner core faster

between the north and south poles (blue arrows)

than across the equator (green arrow)




  • Researchers studied seismic waves from earthquakes as they travel in the Earth


  • This allowed them to detect signs that the core was growing faster in the east


  • The authors say it hasn't left the core lopsided as gravity evens out distribution
    It allowed them to pin down the age of the inner core to 0.5 to 1.5 billion years




Our planet's solid-iron inner core has been growing faster on one side than the other for more than half a billion years, study finds

The solid-iron inner core of the Earth has been growing faster on one side than the other for over 500 million years, according to a new study.

It is growing faster under Indonesia's Banda Sea than under Brazil, but this uneven growth pattern hasn't left the core lopsided, say seismologists at the University of California, Berkeley, who have been investigating the phenomenon.

Gravity has acted to evenly distribute the new growth, made up of iron crystals that form as molten iron begins to cool, maintaining a spherical inner core.

Even though it doesn't leave the core lopsided, this uneven growth rate suggests something in the outer core under Indonesia is removing heat from the inner core at a faster rate than it is under Brazil on the opposite side of the planet, the team said.

Researchers say this discovery has helped them 'prove rather loose bounds' for the age of the inner core, to between half a billion and 1.5 billion years.

This boundary for the age of the solid core of the Earth can help scientists learn more about the magnetic field, which protects us from harmful solar radiation.

'It can help in the debate about how the magnetic field was generated prior to the existence of the solid inner core,' said Barbara Romanowicz, study co-author.

'We know the magnetic field already existed 3 billion years ago, so other processes must have driven convection in the outer core at that time.'

The youngish age of the inner core may mean that, early in Earth's history, the heat boiling the fluid core came from light elements separating from iron, not from crystallization of iron, which we see today.

'Debate about the age of the inner core has been going on for a long time,' said Daniel Frost, assistant project scientist.

'The complication is: If the inner core has been able to exist only for 1.5 billion years, based on what we know about how it loses heat and how hot it is, then where did the older magnetic field come from?

'That is where this idea of dissolved light elements that then freeze out came from.'

Asymmetric growth of the inner core, that is growing at different rates on each side of the planet, explains a three-decade-old mystery, Daniel Frost explained.

The mystery is that the crystallized iron in the core seemed to be more likely to be aligned to the west than the east of Earth's rotational axis.




Map showing the seismometers (triangles)

at which the researchers measured seismic waves

from earthquakes (circles) to study Earth's inner core



The team say scientists would expect the crystals to be randomly oriented than have them favor one side of the planet than the other.

In an attempt to explain the observations, they created a computer model of crystal growth in the inner core.

Their model incorporated geodynamic growth, how materials on earth deform and form, and the mineral physics of iron at high pressure and high temperature.

'The simplest model seemed unusual - that the inner core is asymmetric,' Frost said.

'The west side looks different from the east side all the way to the center, not just at the top of the inner core, as some have suggested. The only way we can explain that is by one side growing faster than the other.'

The model describes how asymmetric growth - about 60 per cent higher in the east than the west - can preferentially orient iron crystals along the rotation axis, with more alignment in the west than in the east.

'What we're proposing in this paper is a model of lopsided solid convection in the inner core that reconciles seismic observations and plausible geodynamic boundary conditions,' Romanowicz said.




Even though it doesn't leave the core lopsided,

this uneven growth rate suggests something

in the outer core under Indonesia

 is removing heat from the inner core

 at a faster rate than it is under Brazil

on the opposite side of the planet,

the team said



Earth's interior is layered like an onion.



The solid iron-nickel inner core is 745 miles in radius, or about three-quarters the size of the moon and is surrounded by a fluid outer core of molten iron and nickel about 1,500 miles thick.

The outer core is surrounded by a mantle of hot rock 1,800 miles thick and overlain by a thin, cool, rocky crust at the surface.

Convection occurs both in the outer core, which slowly boils as heat from crystallizing iron comes out of the inner core, and in the mantle, as hotter rock moves upward to carry this heat from the centre of the planet to the surface.




A new model by UC Berkeley seismologists

proposes that Earth's inner core grows faster

 on its east side (left) than on its west.

Gravity equalizes the asymmetric growth

by pushing iron crystals toward

the north and south poles (arrows)



The vigorous boiling motion in the outer core produces Earth's magnetic field.







WHAT IS EARTH'S MAGNETIC FIELD

...AND HOW DOES IT PROTECT US?



Earth's magnetic field is a layer of electrical charge that surrounds our planet.

The field protects life on our planet because it deflects charged particles fired from the sun known as 'solar wind'.

Without this protective layer, these particles would likely strip away the Ozone layer, our only line of defense against harmful UV radiation.

Scientists believe the Earth's core is responsible for creating its magnetic field. As molten iron in the Earth's outer core escapes it creates convection currents.

These currents generate electric currents which create the magnetic field in a natural process known as a geodynamo.



According to Frost's computer model, as iron crystals grow, gravity redistributes the excess growth in the east toward the west within the inner core.

Movement of crystals in the inner core, close to the melting point of iron, aligns the crystal lattice with the Earth's rotational axis - doing so more to the west than the east, they found.

The model correctly predicts the researchers' new observations about seismic wave travel times through the inner core.

The anisotropy, or difference in travel times parallel and perpendicular to the rotation axis, increases with depth.

The strongest anisotropy is offset to the west from Earth's rotation axis by about 250 miles.

The model of inner core growth also provides limits on the proportion of nickel to iron in the centre of the earth, Frost said.

His model does not accurately reproduce seismic observations unless nickel makes up between four per cent and eight per cent of the inner core.

This is close to the proportion in metallic meteorites that once were the cores of dwarf planets in our solar system.

The model also tells geologists how viscous, or fluid, the inner core is.

'We suggest that the viscosity of the inner core is relatively large,' said Romanowicz.

This is 'an input parameter of importance to geodynamicists studying the dynamo processes in the outer core.'

The findings are due to be presented in the the journal Nature Geoscience.










EARTH'S LIQUID IRON CORE CREATES THE MAGNETIC FIELD

Our planet's magnetic field is believed to be generated deep down in the Earth's core.

Nobody has ever journeyed to the centre of the Earth, but by studying shockwaves from earthquakes, physicists have been able to work out its likely structure.

At the heart of the Earth is a solid inner core, two thirds of the size of the moon, made mainly of iron.

At 5,700°C, this iron is as hot as the Sun's surface, but the crushing pressure caused by gravity prevents it from becoming liquid.

Surrounding this is the outer core there is a 1,242 mile (2,000 km) thick layer of iron, nickel, and small quantities of other metals.









The metal here is fluid, because of the lower pressure than the inner core.

Differences in temperature, pressure and composition in the outer core cause convection currents in the molten metal as cool, dense matter sinks and warm matter rises.

The 'Coriolis' force, caused by the Earth's spin, also causes swirling whirlpools.

This flow of liquid iron generates electric currents, which in turn create magnetic fields. Charged metals passing through these fields go on to create electric currents of their own, and so the cycle continues.

This self-sustaining loop is known as the geodynamo.

The spiraling caused by the Coriolis force means the separate magnetic fields are roughly aligned in the same direction, their combined effect adding up to produce one vast magnetic field engulfing the planet.
